MXC, DDS5900 and DCS6000

MXC Firmware

For Shure Discussion System Products

Keep your conference system performing at its best with the latest easy-to-use and free-to-download firmware packages. These downloads include Firmware Update Utility which helps you update compatible Shure products (MXC, DDS5900, and DCS6000) while managing all of your device firmware. The MXC Firmware Update Utility (FUU) is bundled with the firmware download on the Shure website. Use this program to keep your system updated to the latest firmware version, or to upload image files to compatible conference units. For any questions see the MXC User Guide or contact support for assistance.

Download MXC Firmware

Version 9.2.0 | View All Updates

Download Windows 64-bit

Download

Reviews

Compatible Products

DIS-CCU

Central Control Unit

Central control unit for use with MXC-series, 5900-series, or 6000-series conference and discussion units.

Support

Customer Support

Service & Repair

Detailed policy information regarding customer service numbers, service modifications, and replacement parts.

Service & Repair

Contact Us

Submit a ticket directly to Shure Customer Service staff, or reach out via phone or email.

Contact Us

Resources

Shure Tech Portal

Complete product documentation, technical support materials, software and firmware, and other tools and resources for all Shure products, in one place.

Sign In launch

Documentation

Firmware Compatibility Chart

Release Notes

Version 9.2.0

Release notes cover the following models:

  • MXC605/605-F
  • MXC615
  • MXC620/620-F
  • MXC630/630-F
  • MXC640
  • MXCIC
  • MXCMIU
  • MXCSIGN
  • DIS-CCU
  • AO6004
  • DC5900F
  • DC5980P
  • DCS6000 legacy conference and interpreter units

Important

  • This firmware release can be used to update:
    • Microflex Complete (MXC) or DCS 6000 systems using DIS-CCU Central Unit
    • DC5900F and DC5980P to register and work in an MXC system
  • Systems using CU 5905, CU 6000, CU 6005, CU 6010, CU 6011, CU 6105, or CU 6110 Central Units are not supported in this release
  • The update requires using the Firmware Update Utility (FUU) included in this release

New Features

  • System
    • Support for Mifare/Desfire card when used with SW6000
      • When using SW6000, the MXC system can now be configured to provide:
        • The User ID/Login code data from ACOS3 NFC cards programmed from SW6000 (current feature) or
        • The Unique ID on a Mifare/Desfire NFC card or an ACOS3 NFC card (new feature)
      • Benefits
        • Using the Unique ID enables usage of cards where no (meeting) data has been written to the card
        • This makes it possible to use cards that are provided to users for other purposes to login to SW6000, so the user needs to hold one less card
      • Important
        • Mifare/Desfire NFC cards can only be used with SW6000 connected, not in a standalone system
  • DIS-CCU 
    • Support for setting output/level on the AO6004 Audio Output unit
    • Additional languages – Polish & Croatian
    • System Information Report – Information content updated
    • Support for configuring MXCMIU as Interpreter source
    • Support for configuring MXC605 as a voting unit
    • Alternate LED indications. Option to set the microphone ‘Speak/Request color’:
      • Red speak | Green Request
      • Green speak | Green Request
    • Option to disable the Request indication in the gooseneck microphone
    • Disable Global language selection (CGUI) when SW6000 is connected
  • MXCMIU
    • Interpreter Source option
  • MXC640
    • Additional languages – Polish & Croatian
    • Expand Agenda Prefix
  • MXC605
    • Option with new overlay: Voting 2- and 3-buttons, Attendance check, Secret/open voting
  • MXCIC
    • Expand Agenda Prefix
  • MXCSIGN
    • OS updated to allow the use of the USB connector together with the ‘Shure MXCSIGN App’. The app allows to transfer a defined picture to the sign
  • TPCI
    • ‘Speak Slow’ support
    • MIU interpreter source option

Bug Fixes

  • System
    • Ambient sound disappears when switching to VOX mode
  • CCU
    • Web GUI removes only a single unregistered unit at 'Remove unregistered units'
    • Web GUI – Indication in buttons in Diagnostic screen updated
    • Diagnostic – last unit on a chain is reported as lost when reconfigured into loop
    • Floor1 and Floor2 is switched in the web GUI Channel-dropdown
    • Force CCU-configuration to 1000 m of cable, when upgrading from earlier versions to Release 9.2.0
    • The indication for 605 interpreter in 'Diagnostic' is wrong
  • MXCMIU
    • Function button indication is not turning blue, when configured as ambient mic
  • MXC620
    • Unit not reacting to card inserted, when location code is altered
  • MXC620-F & MXC630-F
    • Chairman left button configured as Exclusive can take over other units already in Exclusive state
  • MXC630 and MXC630-F
    • 3-Btn Secret voting with proxy – missing LED indication
    • Cannot login to a meeting during a paused Voting session
    • Indication in proxy button is not correct
    • Secret voting – wrong LED indication
  • MXC640
    • "Attended" text is not translated
    • Misleading texts corrected when logging in with card
    • Missing clear feedback on buttons on login screen
    • Present/seats value = 2000 are cut of in right side, and only 200 is shown
    • Speech time display permissions are not working
    • Voting not possible with meeting mode: No login
  • MXCIC
    • Some units are 'Locked' when the system is powered
    • Unable to turn off "Audible Level Warning"

Known Issues

  • Manually entered voting results are not shown if a normal voting session has not been started first
  • The agenda subject name for a manually entered result may be wrong
  • It is not possible to use an MXC640 configured as dual delegate with SW6000 if the use of NFC cards is enabled

Notes

  • These release notes include notes from the not-released FW 9.1
  • MXC and DCS 6000 firmware files are packaged together in the same release file.
  • To operate MXC devices with FW release 9.2 with other Shure networked systems, see the following list of minimum software and firmware versions:
    • SW6000 9.2.0
    • Shure NFC Programming App 1.0.3
